Specification
| Tare weight | 9000kg |
| Size | 9700mm*2500mm*4000mm customized |
| Volume | 30-100M3 customized |
| Tank body | Q235A/5mm steel sheet V Type |
| End plate | Q235A/6mm ball shape |
| Axle | 3 Axle FUWA/HJ/BPW brand 13/15/16/20T |
| Suspension | Mechanical suspension American type or Air Suspension |
| Leaf spring | Leaf spring 10pcs*90*13mm or 12pcs*100*12mm |
| Manhole cover | 500mm manhole cover 2 sets |
| Tire | 12R22.5/11R22.5/11.00R20/12.00R20 Double star/Triangle brand 12pcs |
| Wheel rim | 9.0-22.5/9.0-20/8.5-20/9.0-20 better brand 12pcs |
| Discharge valve | 4"disc valve |
| Discharge pipe | 4"seamless steel tube |
| Outlet pipe | 4"rubber hose.6m |
| Kingpin | JOST brand 2"/3.5'' bolt-in king pin or welding type |
| Landing gear | JOST brand two-speed, manual operating, heavy duty landing gear 24T |
| Engine | Diesel engine: weichai brand model: 4102. |
| Air compressor | 37 KW, 0.2Mpa. 1000r/Min |
| Compartment | Single |
| Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| ABS | Optional |
| Light | LED 8 side lights and 2 rear lights 2 width lamp |
| Air-charging system | 2"main hole. 2"check valve. 1.5"safe valve. 0.4Mpa.gauge |
| Quadratic blow | 1" diameter check valve |
| Painting | Complete chassis sand blasting to clean rust ,1 coat of anticorrosive prime, 2 coats of final paint Wax sprayed |
| Accessories | One standard tool box, one spare tire carrier, one crank, one shaft head wrench, four side lights, two rear lights |
| Date of delivery | 20 workdays after we received 30% of contract value T/T down payment. |
Truck Tractor Utility Trailer Bulk Cement Tank/Tanker Semi Trailer
Competitive Advantages
1. It's our own factory, advanced equipment and rich experienced workers are applied during the whole producing process to ensure the quality of semi trailers.
2. Optional trailer sizes and styles can be customized
3. Certification: ISO9001:2008, CCC, BV, etc.
4. Small order quantity can be accepted, MOQ is 1 set.
5. Exported to many countries, such as Russia, France, Southeast Asia, Africa and so on more than 20 countries.
Diversity of products
Company Information
Shandong Liangshan Huayu Group Auto Manufactory Co .,Ltd. is an automobile manufacture enterprise approved by the former National Economics and Trade Committee, with "HuaYuDa Brand" automobile products being catalogued into the national automobile product summary announcement. The company engaged in designing, researching manufacturing and selling. The company covers above 800 acres, with total assets of RMB 560,000,000.00 Yuan and factory building areas of 236,000 square meters. Now there are more than 2000 staff, therein 180 senior technical engineers. The company mainly specializing in manufacturing special vehicles such as refitting vehicles, semi trailers, tippers, and oil tank trucks, bulk cement tank, concrete mixer trucks and special operations vehicle, with annual yield of above 10000 sets. The company equips the first-class CNC cutting, advanced equipment of welding and stamping, and excellent quality guarantee system, modern testing means and high qualified specialist technicians. Our company is a special purpose motor vehicle manufacturing enterprise which has large scale of production, perfect Quality Management System in domestic. Products sold throughout the country, some products are exported to Russia, France, southeast Asia, Africa and so on more than 20 countries.
Customer Visiting
FAQ
1. Does your company have your own factory?
Yes, we are manufacturer, we have been in this area for more than 20 years.
You are welcome to visit our factory at anytime!
2. What is your terms of payment?
T/T with 30% deposit, and 70% payment will be made before delivery.
We will show you photos of the products and packages before you paying the balance.
3. What's your minimum quantity?
1 set.
4. What is your packing?
5. How about delivery time?
Hello, We are a big factory located in Shandong Liangshan. We have been in this area for more than 20 years. If you have any special requirements, we can customize for you. We promise you the lowest price, best quality and service. Hope to cooperate with you!
